En otroligt häftig Mini Tank Robot — aktuellt utbud; kontrollera kompatibilitet från Keyestudio som ger massor av underhållning och inte minst lärande! Den kan programmeras med både Arduino IDE och Mixly. Du kan också byta ut olika sensorer och ställdon som moduler, så den här lilla roboten ger mycket för pengarna! Videon nedan visar bara tre av de funktioner som roboten erbjuder, tillsammans med en kort video av bygget. På vår GitHub hittar du alla kodexempel för roboten — aktuellt utbud; kontrollera kompatibilitet, som du hittar här.
Viktig information
För att programmera roboten kan du behöva installera en drivrutin på din Windows-dator så att den kan känna igen Arduino Uno när den ansluts. Drivrutinen kan laddas ned här.
Tanken har en 8x16 LED-matrisskärm framtill som du kan anpassa själv. Det finns en utmärkt webbplats där du enkelt kan rita din bild, som webbplatsen sedan omvandlar till hex-kod att använda i Arduino-koden. Webbplatsen finns här.
Tanken använder 2x 18650-batterier — aktuellt utbud; kontrollera kompatibilitet som inte ingår i paketet. Du behöver också ett CR2032-knappcellsbatteri till IR-fjärrkontrollen. Det finns att köpa här på eBits!
Det finns två huvudsakliga konfigurationer av roboten. Tänk dig att du får två robotar till priset av en: en med ultraljudssensor och fotoresistorer, och en med flamsensorer och fläkt. Bilden nedan visar de ”två” robotarna

APP
Mini Tank Robot V3 — aktuellt utbud; kontrollera kompatibilitet är utrustad med en Bluetooth-modul så att du kan styra tanken och dess många funktioner med telefonen. Både Android- och Apple-telefoner kan användas. Ladda bara ned appen KeyesRobot.
![]() |
Google Play Store https://play.google.com/store/apps/details?id=com.keyestudio.keyestudio App Store Öppna App Store → Sök efter KeyesRobot → Ladda ned appen till telefonen |
När du öppnar appen trycker du först på Bluetooth-knappen i högra hörnet. En meny visas där du kan ansluta till Mini Tank Robot V3 — aktuellt utbud; kontrollera kompatibilitet. Välj sedan roboten som visas mitt på skärmen. Nu visas många funktioner för att styra roboten. Titta gärna på presentationsvideon.
![]() |
|
Bygg tanken
Bildserien nedan visar hur själva tanken monteras. Montera först 8x16 LED-matrisen och skruva fast den på akrylplattan.






Bygg tanken med ultraljudssensor och fotoresistorer
Nedan går vi igenom hur roboten monteras med ultraljudssensor och fotoresistorer. Fäst först ultraljudssensorn på den böjda akrylplattan.





|
|

|
|
|
![]() |
Bygg tanken med flamsensorer och fläkt
Bilderna nedan visar hur du byter till fläkt och flamsensorer. Observera att anslutningskablarna också behöver bytas till de andra som ingår i paketet. Men oroa dig inte: kablarna som passar fotoresistorerna passar inte flamsensorerna.


IR-fjärrkontroll
Följande exempel bygger på att styra roboten — aktuellt utbud; kontrollera kompatibilitet med infrarött ljus. Paketet innehåller en liten fjärrkontroll som använder ett litet 3V-knappcellsbatteri. Dessa finns i din lokala butik.
Koden nedan gör att du kan köra framåt, bakåt, åt höger och åt vänster. Du måste dock importera två bibliotek till din libraries-mapp. Den finns under Dokument -> Arduino -> libraries.
De två biblioteken finns här
#include <IRremote.h>
IRrecv irrecv(A2); //
decode_results results;
long ir_rec; // used to save the IR value
//Array, used to save data of images, can be calculated by yourself or gotten from modulus tool
unsigned char start01[] = {0x01, 0x02, 0x04, 0x08, 0x10, 0x20, 0x40, 0x80, 0x80, 0x40, 0x20, 0x10, 0x08, 0x04, 0x02, 0x01};
unsigned char front[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x12, 0x09, 0x12, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char back[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x48, 0x90, 0x48, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char left[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x00};
unsigned char right[] = {0x00, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char STOP01[] = {0x2E, 0x2A, 0x3A, 0x00, 0x02, 0x3E, 0x02, 0x00, 0x3E, 0x22, 0x3E, 0x00, 0x3E, 0x0A, 0x0E, 0x00};
unsigned char clear[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
#define SCL_Pin A5 //set the pin of clock to A5
#define SDA_Pin A4 //set the data pin to A4
#define ML_Ctrl 4 //define the direction control pin of the left motor as 4
#define ML_PWM 5 //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2 //define the direction control pin of the right sensor as 2
#define MR_PWM 6 //define the PWM control pin of the right motor as 9
void setup() {
Serial.begin(9600);
irrecv.enableIRIn(); //initialize the IR reception library
pinMode(ML_Ctrl, OUTPUT);
pinMode(ML_PWM, OUTPUT);
pinMode(MR_Ctrl, OUTPUT);
pinMode(MR_PWM, OUTPUT);
pinMode(SCL_Pin, OUTPUT);
pinMode(SDA_Pin, OUTPUT);
matrix_display(clear); //Clear screens
matrix_display(start01); //display the image of start
}
void loop() {
if (irrecv.decode(&results)) { //receive the value of IR remote
ir_rec = results.value;
String type = "UNKNOWN";
String typelist[14] = {"UNKNOWN", "NEC", "SONY", "RC5", "RC6", "DISH", "SHARP", "PANASONIC", "JVC", "SANYO", "MITSUBISHI", "SAMSUNG", "LG", "WHYNTER"};
if (results.decode_type >= 1 && results.decode_type <= 13) {
type = typelist[results.decode_type];
}
Serial.print("IR TYPE:" + type + " ");
Serial.println(ir_rec, HEX);
irrecv.resume();
}
switch (ir_rec) {
case 0xFF629D: Car_front(); break; //the command to go front
case 0xFFA857: Car_back(); break; //the command to go back
case 0xFF22DD: Car_T_left(); break; //the command to turn left
case 0xFFC23D: Car_T_right(); break; //the command to turn right
case 0xFF02FD: Car_Stop(); break; //the command to stop
case 0xFF30CF: Car_left(); break; //the command to rotate to left
case 0xFF7A85: Car_right(); break; //the command to rotate to right
default: break;
}
}
/***************motor works***************/
void Car_front() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 200);
matrix_display(front); //show the image to go front
}
void Car_back() {
digitalWrite(MR_Ctrl, HIGH);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, HIGH);
analogWrite(ML_PWM, 200);
matrix_display(back); //show the image to go back
}
void Car_left() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, HIGH);
analogWrite(ML_PWM, 200);
matrix_display(left); //show the image to rotate to left
}
void Car_right() {
digitalWrite(MR_Ctrl, HIGH);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 200);
matrix_display(right); //show the image to rotate to right
}
void Car_Stop() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 0);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 0);
matrix_display(STOP01); //show the image to stop
}
void Car_T_left() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 255);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 150);
matrix_display(left); //show the image to turn left
}
void Car_T_right() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 150);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 255);
matrix_display(right); //show the image to turn right
}
//this function is used for a dot matrix
void matrix_display(unsigned char matrix_value[])
{
IIC_start(); //use the function to start transmitting data
IIC_send(0xc0); //select an address
for (int i = 0; i < 16; i++) //image data have 16 characters
{
IIC_send(matrix_value[i]); //data to transmit pictures
}
IIC_end(); //end the data transmission of pictures
IIC_start();
IIC_send(0x8A); //show control and select pulse width 4/16
IIC_end();
}
//the condition that data starts transmitting
void IIC_start()
{
digitalWrite(SDA_Pin, HIGH);
digitalWrite(SCL_Pin, HIGH);
delayMicroseconds(3);
digitalWrite(SDA_Pin, LOW);
delayMicroseconds(3);
digitalWrite(SCL_Pin, LOW);
}
//the sign that transmission of data ends
void IIC_end()
{
digitalWrite(SCL_Pin, LOW);
digitalWrite(SDA_Pin, LOW);
delayMicroseconds(3);
digitalWrite(SCL_Pin, HIGH);
delayMicroseconds(3);
digitalWrite(SDA_Pin, HIGH);
delayMicroseconds(3);
}
//transmit data
void IIC_send(unsigned char send_data)
{
for (byte mask = 0x01; mask != 0; mask <<= 1) //ecah character has 8 digits, which is detected one by one
{
if (send_data & mask) { //set high or low levels in light of each bit(0 or 1)
digitalWrite(SDA_Pin, HIGH);
} else {
digitalWrite(SDA_Pin, LOW);
}
delayMicroseconds(3);
digitalWrite(SCL_Pin, HIGH); //pull up the clock pin SCL_Pin to end the transmission of data
delayMicroseconds(3);
digitalWrite(SCL_Pin, LOW); //pull down the clock pin SCL_Pin to change signals of SDA
}
}
Ultraljudsföljare
Ett roligt litet exempel som använder ultraljudssensorn för att följa din hand eller ett föremål. Om handen eller föremålet kommer för nära börjar roboten backa. Här är koden där du kan ändra önskade avstånd. Det är ett bra sätt att experimentera med ultraljudssensorer och förstå hur man räknar om till avstånd.
/*
keyestudio Mini Tank Robot V3
lesson 14
Ultrasonic follow tank
http://www.keyestudio.com
*/
#define servoPin 10 //the pin of the servo
#define ML_Ctrl 4 //define define the control pin of the left motor as 4
#define ML_PWM 5 //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2 //define the control pin of the right motor as 2
#define MR_PWM 6 //define the PWM control pin of the right motor as 9
#define Trig 12
#define Echo 13
float distance;
void setup() {
pinMode(servoPin, OUTPUT);
pinMode(Trig, OUTPUT);
pinMode(Echo, INPUT);
pinMode(ML_Ctrl, OUTPUT);
pinMode(ML_PWM, OUTPUT);
pinMode(MR_Ctrl, OUTPUT);
pinMode(MR_PWM, OUTPUT);
procedure(0); //set the angle of the servo to 90°
delay(500); //delay in 500ms
}
void loop() {
distance = checkdistance(); //distance assign the distance detected by an ultrasonic sensor
if (distance >= 20 && distance <= 60) //the range to go front
{
Car_front();
}
else if (distance > 10 && distance < 20) //the range to stop
{
Car_Stop();
}
else if (distance <= 10) //the range to go back
{
Car_back();
}
else //or else, stop
{
Car_Stop();
}
}
void Car_front()
{
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 200);
}
void Car_back()
{
digitalWrite(MR_Ctrl,HIGH);
analogWrite(MR_PWM,200);
digitalWrite(ML_Ctrl,HIGH);
analogWrite(ML_PWM,200);
}
void Car_left()
{
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, HIGH);
analogWrite(ML_PWM, 200);
}
void Car_right()
{
digitalWrite(MR_Ctrl, HIGH);
analogWrite(MR_PWM, 200);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 200);
}
void Car_Stop()
{
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 0);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 0);
}
//a function to control servos
void procedure(byte myangle) {
int pulsewidth;
for (int i = 0; i < 5; i++) {
pulsewidth = myangle * 11 + 500; //calculate the value of pulse width
digitalWrite(servoPin, HIGH);
delayMicroseconds(pulsewidth); //the time that high level maintains is pulse width
digitalWrite(servoPin, LOW);
delay((20 - pulsewidth / 1000)); //The cycle is 20ms
}
}
//a function to control the ultrasonic sensor
float checkdistance() {
static float distance;
digitalWrite(Trig, LOW);
delayMicroseconds(2);
digitalWrite(Trig, HIGH);
delayMicroseconds(10);
digitalWrite(Trig, LOW);
distance = pulseIn(Echo, HIGH) / 58.20; //2*29.1=58.2
delay(10);
return distance;
}
Multifunktionstank
Här är ett exempel där många av de häftiga funktionerna är implementerade. Vissa funktioner är bortkommenterade och kan användas i stället om du vill. Implementeringen låter dig styra roboten via Bluetooth och använda fläkten, LED-matrisen och mycket mer.
Det är viktigt att ta bort Bluetooth-modulen när du laddar upp koden nedan, annars kan uppladdningsfel uppstå. Anslut Bluetooth-modulen igen efteråt.
/*
keyestudio Mini Tank Robot V3
lesson 22
multiple functions
http://www.keyestudio.com
*/
#include <IRremote.h>
IRrecv irrecv(A2); //
decode_results results;
long ir_rec; //used to save the IR value
//Array, used to save data of images, can be calculated by yourself or gotten from modulus tool
unsigned char start01[] = {0x01, 0x02, 0x04, 0x08, 0x10, 0x20, 0x40, 0x80, 0x80, 0x40, 0x20, 0x10, 0x08, 0x04, 0x02, 0x01};
unsigned char STOP01[] = {0x2E, 0x2A, 0x3A, 0x00, 0x02, 0x3E, 0x02, 0x00, 0x3E, 0x22, 0x3E, 0x00, 0x3E, 0x0A, 0x0E, 0x00};
unsigned char front[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x12, 0x09, 0x12, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char back[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x48, 0x90, 0x48, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char left[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x00};
unsigned char right[] = {0x00, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char Smile[] = {0x00, 0x00, 0x1c, 0x02, 0x02, 0x02, 0x5c, 0x40, 0x40, 0x5c, 0x02, 0x02, 0x02, 0x1c, 0x00, 0x00};
unsigned char Disgust[] = {0x00, 0x00, 0x02, 0x02, 0x02, 0x12, 0x08, 0x04, 0x08, 0x12, 0x22, 0x02, 0x02, 0x00, 0x00, 0x00};
unsigned char Happy[] = {0x02, 0x02, 0x02, 0x02, 0x08, 0x18, 0x28, 0x48, 0x28, 0x18, 0x08, 0x02, 0x02, 0x02, 0x02, 0x00};
unsigned char Squint[] = {0x00, 0x00, 0x00, 0x41, 0x22, 0x14, 0x48, 0x40, 0x40, 0x48, 0x14, 0x22, 0x41, 0x00, 0x00, 0x00};
unsigned char Despise[] = {0x00, 0x00, 0x06, 0x04, 0x04, 0x04, 0x24, 0x20, 0x20, 0x26, 0x04, 0x04, 0x04, 0x04, 0x00, 0x00};
unsigned char Heart[] = {0x00, 0x00, 0x0C, 0x1E, 0x3F, 0x7F, 0xFE, 0xFC, 0xFE, 0x7F, 0x3F, 0x1E, 0x0C, 0x00, 0x00, 0x00};
unsigned char eBits[] = {0x7e, 0x52, 0x52, 0x00, 0x7e, 0x4a, 0x7e, 0x00, 0x7e, 0x00, 0x02, 0x7e, 0x02, 0x5e, 0x52, 0x72
};
unsigned char clear[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
#define SCL_Pin A5 //set the pin of clock to A5
#define SDA_Pin A4 //set the data pin to A4
#define ML_Ctrl 4 //define the direction control pin of the left motor as 4
#define ML_PWM 5 //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2 //define the direction control pin of the right sensor as 2
#define MR_PWM 6 //define the PWM control pin of the right motor as 6
char ble_val; //used to save the Bluetooth value
byte speeds_L = 200; //the initial speed of the left motor is 200
byte speeds_R = 200; // the initial speed of the right motor is 200
String speeds_l, speeds_r; //receive PWM characters and convert them into PWM value
//#define light_L_Pin D3 //define the pin of the left photoresistor
//#define light_R_Pin A1 //define the pin of the right photoresistor
int left_light;
int right_light;
int flame_L = 3; //define the analog port of the left flame sensor to A0
int flame_R = A1; //define the analog port of the right flame sensor to A1
//wire up the line tracking sensor
#define L_pin 11 //left
#define M_pin 7 //middle
#define R_pin 8 //right
int L_val, M_val, R_val, flame_valL, flame_valR;
//the pin of 130 motor
int INA = 12;
int INB = 13;
//#define Trig 12
//#define Echo 13
float distance;//Store the distance values detected by ultrasonic for following
//Store the distance values detected by ultrasonic for obstacle avoidance
int a;
int a1;
int a2;
#define servoPin 10 //servo Pin
bool flag; // flage invarible, used to enter and exit a mode
void setup() {
Serial.begin(9600);
irrecv.enableIRIn(); //Initialize the library of the IR remote
// pinMode(light_L_Pin, INPUT);
// pinMode(light_R_Pin, INPUT);
//define the pins of sensors to INPUT
pinMode(flame_L, INPUT);
pinMode(flame_R, INPUT);
// pinMode(Trig, OUTPUT);
// pinMode(Echo, INPUT);
pinMode(ML_Ctrl, OUTPUT);
pinMode(ML_PWM, OUTPUT);
pinMode(MR_Ctrl, OUTPUT);
pinMode(MR_PWM, OUTPUT);
pinMode(L_pin, INPUT); //set pins of the line tracking sensor to INPUT
pinMode(M_pin, INPUT);
pinMode(R_pin, INPUT);
pinMode(servoPin, OUTPUT);
pinMode(SCL_Pin, OUTPUT);
pinMode(SDA_Pin, OUTPUT);
pinMode(INA, OUTPUT);//set INA to OUTPUT
pinMode(INB, OUTPUT);//set INB to OUTPUT
matrix_display(clear); //clear screens
matrix_display(start01); //show start
procedure(90); //set the angle of the servo to 90°
}
void loop() {
if (Serial.available()) //if there is data in the serial buffer
{
ble_val = Serial.read();
Serial.println(ble_val);
switch (ble_val) {
case 'F': Car_front(); break; //the command to go front
case 'B': Car_back(); break; //the command to go back
case 'L': Car_left(); break; //the command to turn left
case 'R': Car_right(); break; //the command to turn right
case 'S': Car_Stop(); break; //the command to stop
case 'e': Tracking(); break; //enter the line tracking mode
case 'f': Confinement(); break; //enter the confinement mode
// case 'g': Avoid(); break; //enter the obstacle avoidance mode
// case 'h': Follow(); break; //enter the line tracking mode
// case 'i': Light_following(); break; //enter light following mode
case 'j': Fire(); break; //enter the mode to put out fire
case 'c': fan_begin(); break; //start the fan
case 'd': fan_stop(); break; //turn off the fan
case 'u': speeds_l = Serial.readStringUntil('#'); speeds_L = String(speeds_l).toInt(); break; //start by receiving u, end by receiving characters # and convert into the integer
case 'v': speeds_r = Serial.readStringUntil('#'); speeds_R = String(speeds_r).toInt(); break; //start by receiving u, end by receiving characters # and convert into the integer
case 'k': matrix_display(Smile); break; //show "smile" face
case 'l': matrix_display(Disgust); break; //show "disgust" face
case 'm': matrix_display(Happy); break; //show "happy" face
case 'n': matrix_display(Squint); break; //show "Sad" face
case 'o': matrix_display(Despise); break; //show "despise" face
case 'p': matrix_display(Heart); break; //show the hearbeat image
case '1': matrix_display(eBits); break; //show the eBits image
case 'z': matrix_display(clear); break; //clear images
default: break;
}
}
//the following signals are used to print out
/*if(ble_val == 'x'){
distance = checkdistance(); Serial.println(distance);
delay(50);
}else if(ble_val == 'w'){
left_light = analogRead(light_L_Pin);
Serial.println(left_light);
delay(50);
}else if(ble_val == 'y'){
right_light = analogRead(light_R_Pin);
Serial.println(right_light);
delay(50);
}*/
if (irrecv.decode(&results)) { //receive the value detected by IR remote
ir_rec = results.value;
Serial.println(ir_rec, HEX);
switch (ir_rec) {
case 0xFF629D: Car_front(); break; //the command to go front
case 0xFFA857: Car_back(); break; //the command to go back
case 0xFF22DD: Car_left(); break; //the command to rotate to left
case 0xFFC23D: Car_right(); break; //the command to rotate to right
case 0xFF02FD: Car_Stop(); break; //the command to stop
default: break;
}
irrecv.resume();
}
}
/*****************obstacle avoidance******************/
/*void Avoid()
{
flag = 0;
while (flag == 0)
{
a = checkdistance(); //set the front distance detected by the ultrasonic sensor to a
if (a < 20) {//when the front distance is less than 20cm
Car_Stop(); //robot stops
delay(500); //delay in 500ms
procedure(180); //servo platform turns left
delay(500); //delay in 500ms
a1 = checkdistance(); //set the left distance detected by the ultrasonic sensor to a1
delay(100); //read value
procedure(0); //servo platform turns right
delay(500); //delay in 500ms
a2 = checkdistance(); //set the right distance detected by the ultrasonic sensor to a2
delay(100); //read value
procedure(90); //back to 90°
delay(500);
if (a1 > a2) { //the left distance is larger than the right
Car_left(); //robots turn left
delay(700); //turn left for 700ms
} else {
Car_right(); //robot turns right
delay(700);
}
}
else { //if the front distance ≥20cm,robot goes front
Car_front(); //go front
}
// receive the Bluetooth value to exit the loop
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S') //receive S
{
flag = 1; //set flag to 1,exit the loop
Car_Stop();
}
}
}
}*/
/*******************line tracking****************/
/*void Follow() {
flag = 0;
while (flag == 0) {
distance = checkdistance(); //set the distance value to distance
if (distance >= 20 && distance <= 60) //20≤ distance ≤60,go front
{
Car_front();
}
else if (distance > 10 && distance < 20) //10< distance < 20, stop
{
Car_Stop();
}
else if (distance <= 10) //distance≤ 10, go back
{
Car_back();
}
else //or else, stop
{
Car_Stop();
}
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S')
{
flag = 1; //exit the loop
Car_Stop();
}
}
}
}*/
/****************light following******************/
/*void Light_following() {
flag = 0;
while (flag == 0) {
left_light = analogRead(light_L_Pin);
right_light = analogRead(light_R_Pin);
if (left_light > 650 && right_light > 650) //go front
{
Car_front();
}
else if (left_light > 650 && right_light <= 650) //turn left
{
Car_left();
}
else if (left_light <= 650 && right_light > 650) //turn right
{
Car_right();
}
else //or else, stop
{
Car_Stop();
}
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S') {
flag = 1;
Car_Stop();
}
}
}
}*/
/***************put out fire*****************/
void Fire() {
flag = 0;
while (flag == 0) {
//read the analog value of the flame sensor
flame_valL = analogRead(flame_L);
flame_valR = analogRead(flame_R);
if (flame_valL <= 700 || flame_valR <= 700) {
Car_Stop();
fan_begin();
} else {
fan_stop();
L_val = digitalRead(L_pin); //read the value of the left sensor
M_val = digitalRead(M_pin); //read the value of the middle sensor
R_val = digitalRead(R_pin); //read the value of the right one
if (M_val == 1) { //the middle one detects black lines
if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
Car_left();
}
else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
Car_right();
}
else { //go front otherwise
Car_front();
}
}
else { //the middle one doesn't detect black lines
if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
Car_left();
}
else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
Car_right();
}
else { //stop otherwise
Car_Stop();
}
}
}
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S') {
flag = 1;
Car_Stop();
}
}
}
}
/***************line tracking*****************/
void Tracking() {
flag = 0;
while (flag == 0) {
L_val = digitalRead(L_pin); //read the value of the left sensor
M_val = digitalRead(M_pin); //read the value of the middle one
R_val = digitalRead(R_pin); //read the value of the right one
if (M_val == 1) { //the middle one detects black lines
if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
Car_left();
}
else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
Car_right();
}
else { //or else, go front
Car_front();
}
}
else { //the middle one doesn't detect the black line
if (L_val == 1 && R_val == 0) { //if only the left one detect the black line,turn left
Car_left();
}
else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
Car_right();
}
else { //or else, stop
Car_Stop();
}
}
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S') {
flag = 1;
Car_Stop();
}
}
}
}
/***************confinement*****************/
void Confinement() {
flag = 0;
while (flag == 0) {
L_val = digitalRead(L_pin); //read the value of the left sensor
M_val = digitalRead(M_pin); //read the value of the middle one
R_val = digitalRead(R_pin); //read the value of the right one
if ( L_val == 0 && M_val == 0 && R_val == 0 ) { //if no sensor detects black lines, go front
Car_front();
}
else { //or else, any the line tracking sensor can go back and turn left
Car_back();
delay(700);
Car_left();
delay(800);
}
if (Serial.available())
{
ble_val = Serial.read();
if (ble_val == 'S') {
flag = 1;
Car_Stop();
}
}
}
}
//he function to control the ultrasonic
/*float checkdistance() {
float distance;
digitalWrite(Trig, LOW);
delayMicroseconds(2);
digitalWrite(Trig, HIGH);
delayMicroseconds(10);
digitalWrite(Trig, LOW);
distance = pulseIn(Echo, HIGH) / 58.20; // 2*29.1=58.2
delay(10);
return distance;
}*/
//the function to control servo
void procedure(int myangle) {
int pulsewidth;
pulsewidth = map(myangle, 0, 180, 500, 2000); //calculate the pulsewith value
for (int i = 0; i < 5; i++) {
digitalWrite(servoPin, HIGH);
delayMicroseconds(pulsewidth); //the time that high level maintains is pulse width
digitalWrite(servoPin, LOW);
delay((20 - pulsewidth / 1000)); //The cycle is 20ms
}
}
/***************fan rotates*****************/
void fan_begin() {
digitalWrite(INA, LOW);
digitalWrite(INB, HIGH);
}
/***************fan stops rotating*****************/
void fan_stop() {
digitalWrite(INA, LOW);
digitalWrite(INB, LOW);
}
/***************dot matrix*****************/
///this function is used for the display of dot matrix
void matrix_display(unsigned char matrix_value[])
{
IIC_start(); //use the function to start transmitting data
IIC_send(0xc0); //select an address
for (int i = 0; i < 16; i++) //image data have 16 characters
{
IIC_send(matrix_value[i]); //data to transmit pictures
}
IIC_end(); //end the data transmission of pictures
IIC_start();
IIC_send(0x8A); //show control and select pulse width 4/16
IIC_end();
}
//the condition that data starts transmitting
void IIC_start()
{
digitalWrite(SDA_Pin, HIGH);
digitalWrite(SCL_Pin, HIGH);
delayMicroseconds(3);
digitalWrite(SDA_Pin, LOW);
delayMicroseconds(3);
digitalWrite(SCL_Pin, LOW);
}
//transmit data
void IIC_send(unsigned char send_data)
{
for (byte mask = 0x01; mask != 0; mask <<= 1) //ecah character has 8 digits, which is detected one by one
{
if (send_data & mask) { //set high or low levels in light of each bit(0 or 1)
digitalWrite(SDA_Pin, HIGH);
} else {
digitalWrite(SDA_Pin, LOW);
}
delayMicroseconds(3);
digitalWrite(SCL_Pin, HIGH); //pull up the clock pin SCL_Pin to end the transmission of data
delayMicroseconds(3);
digitalWrite(SCL_Pin, LOW); //pull down the clock pin SCL_Pin to change signals of SDA
}
}
//the sign that transmission of data ends
void IIC_end()
{
digitalWrite(SCL_Pin, LOW);
digitalWrite(SDA_Pin, LOW);
delayMicroseconds(3);
digitalWrite(SCL_Pin, HIGH);
delayMicroseconds(3);
digitalWrite(SDA_Pin, HIGH);
delayMicroseconds(3);
}
/***************motor runs***************/
void Car_front() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, speeds_R);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, speeds_L);
matrix_display(front); //show the image of going front
}
void Car_back() {
digitalWrite(MR_Ctrl, HIGH);
analogWrite(MR_PWM, speeds_R);
digitalWrite(ML_Ctrl, HIGH);
analogWrite(ML_PWM, speeds_L);
matrix_display(back); //show the image of going back
}
void Car_left() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, speeds_R);
digitalWrite(ML_Ctrl, HIGH);
analogWrite(ML_PWM, speeds_L);
matrix_display(left); //show the image of turning left
}
void Car_right() {
digitalWrite(MR_Ctrl, HIGH);
analogWrite(MR_PWM, speeds_R);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, speeds_L);
matrix_display(right); //show the image of turning right
}
void Car_Stop() {
digitalWrite(MR_Ctrl, LOW);
analogWrite(MR_PWM, 0);
digitalWrite(ML_Ctrl, LOW);
analogWrite(ML_PWM, 0);
matrix_display(STOP01); //show the stop image
}
Programmering med Mixly
Som nämnts kan du också programmera med Mixly, vilket mer liknar att bygga med klossar. Det är en bra introduktion till programmering. Ladda ned och installera programmet på din dator.
| Windows | https://www.dropbox.com/s/mb3vxcn30jwvwxv/Mixly%20for%20windows.7z?dl=0 |
| MAC | https://www.dropbox.com/s/gcllwqpquwyy77c/Mixly_for_keyestudio_MacOS.zip?dl=0 |
När du har laddat ned programmet är det viktigt att välja Arduino UNO som kort.

Bilden nedan visar ett enkelt blinkprogram byggt i Mixly.

På vår GitHub finns kodexempel som använder Mixly för programmering. Länken finns här.
För en grundlig introduktion till Mixly rekommenderar vi följande dokumentation.
